ST3
ST3 Series Spring-cage Terminal Block The ST3 series of cage-type spring terminal blocks, its designs conform to the sta
Basic Info.
Model NO. | ST3-16 |
Character | Environmental Protection |
Species | Terminal |
Production Process | Injection Molding |
Shape | Square |
Interface Type | AC/DC |
Certification | VDE, CE, Ex, RoHS |
Brand | Sipun |
Sreipping Lenth | 18 mm |
Flexible Wire | 2.5-16 mm2 |
Weight | 35g/PCS |
Packing Detail | 100PCS/Box, 3000PCS/CTN |
Color | Grey, Blue, Red, Black |
Rated Current | 90 a |
Solid Wire | 2.5-25 mm2 |
Section | 16 mm2 |
Rated Voltage | 800 V |
Size(W/L/H) | 12.2*80.5*50.5 mm |
Transport Package | Carton |
Trademark | SIPUN |
Origin | China |
HS Code | 8536909000 |
Production Capacity | 100000000 Pieces/Year |
Product Description
ST3 Series Spring-cage Terminal Block The ST3 series of cage-type spring terminal blocks, its designs conform to the standard of IEC60947-7-1, IEC60947-7-2, GB14048.7 and GB14048.8. This product is apply to ac 50Hz(60Hz), and the maximum nominal voltage and rated cross section are 800V and 1.5-35mm, respectively. Besides, it is small and easy to use and has a good resistance to shock. The frontal incoming line ensures the good operation visibility, and this saves the space of incoming line.Model Name: | ST3-16 |
W/L/H mm: | 12.2*80.5*50.5 |
Rated Voltage (V): | 800 |
Rated Current (A): | 90 |
Solid Wire Range mm: | 2.5-25 |
Flexible Wire Range mm: | 2.5-16 |
Stripping Length mm: | 18 |
Material of Shell: | PA66 |
Material of Conductor: | Copper |
Install Rail: | TH35-7.5 / TH35-15 |
Cover: | ST3-16G |
Jumper | UFB 2-12 |
Marker | ZB12 |
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory
Q: How long is your delivery time.A: Generally it is 2-3 days if the goods are in stock. or it is 7-20 days if the goods are not in stock, it is according to quantity
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight
Q: What is your terms of payment ?
A: If we are the first time cooperation , 100% in advance.
